IMETCO's Snap-Lok™ is a medium-height architectural standing seam panel. With its factory-applied sealant and internal gutter feature, the Snap-Lok panel is impervious to water leakage.

Snap-Lok™ Design Characteristics:

• 1¾-inch integral standing seam design provides excellent wind uplift resistance

• Simple one step installation - no seaming tools required

• Heavy duty 18 gauge UL concealed clips accommodate thermal movement

• Factory-applied seam sealant never comes in contact with panel clips

• 3/8-inch clearance between panel and substrate promotes ventilation

• Available in 10-, 12-, 16-, and 18-inch panel widths

• Panel striations offered as a standard

• Weather-tight internal gutter/anti-siphon feature

• Can be installed over open purlins or solid substrate with slopes as little as 1/2:12

• Available in 22 or 24 gauge steel (including stainless), and .032 aluminum

Warranties*

• 20-year finish warranty for Kynar® fluorocarbon coating

• Waterials and workmanship warranty

• Watertight warranty on qualifying applications

* Sample warranties are available and we encourage their inclusion in specifications as a guide during the bidding process

Contact us today for more information about Snap-Lok!
